Alfen Eve Single Pro-line 22kW RFID

  The Alfen Eve Single Pro-line is suitable for both home and business use. With a charging capacity of 22 kW and smart features connected to a back office, you can view energy consumption and transaction history of the charging sessions. The charging station is designed to maximize charging speeds and optimize energy usage without overloading the electrical grid. The compact design of the charging station is robust and durable, and with an IP 54 protection rating, outdoor installation is also possible. The full-color 3.5″ display makes it easy to use with a user-friendly interface and includes the option to upload a logo to enhance your branding. An integrated RFID reader supports user login via Plug & Charge, charging card, or badge.

Features and Benefits of the Alfen Eve Single Pro-line

Robust

Made using polycarbonate reinforced with fiberglass, the Alfen Eve Single Pro-line is robust yet lightweight. The quality of the material makes it very reliable in an outdoor environment. It can also be mounted directly on a wall or on a pedestal, making installation convenient and hassle-free.

LED and LCD

The Alfen Eve Single Pro-line features four colored LEDs with charging status icons, making the charging process easy to understand for any EV charger user. The large 7″ colored LCD also makes the charging point easy to operate, and for an additional cost, you can add your company logo to the screen of your Alfen Eve Single Pro-line.

Charging Management

With integrated charge management, the Alfen Eve Single Pro-line ensures your vehicle always receives the full charging capacity. With a maximum charging power of 22kW, the EV charger evenly distributes the charging power among all connected vehicles charging at the same time.

Plug & Charge or RFID Support

To ensure that only authorized users can use your Alfen Eve Single Pro-line, RFID authorization is provided. This means that only EV drivers with the RFID card can unlock and use the EV charging point. If you do not wish to use the RFID function, you can easily deactivate it and switch to the Plug & Charge function, where the charging station is informed about the type of EV the user is driving and charges accordingly.

Fast Charging

The Alfen Eve Single Pro-line is compatible with all EVs on the market with type-1 or type-2 sockets. Additionally, the Alfen Eve Single Pro-line charges your EV 10 times faster compared to the conventional household socket.

Built-in Protection

The Alfen Eve Single Pro-line has two type B residual current devices. Type B residual current devices have two leakage current detection systems, meaning even if the line voltage fails, a leakage current fault can still be detected. These devices protect the EV charger from AC and DC residual currents.

Communication Flexibility

As a charging station at work or in a public charging domain, the Alfen Eve Single Pro-line can be easily integrated into your network via a cable connection, such as a LAN cable or a powerline adapter. Billing and charging can also be handled by an OCPP-supported external management system provider of your choice. Alternatively, communication without cables is also possible using a SIM card.

Includes 2-Year Warranty

The Alfen Single Pro comes with a 2-year warranty for material and manufacturing defects. Have a question about the warranty? Feel free to contact our customer service. We are happy to help! Want to know more about Alfen Eve Single Pro-line? Brochure Alfen Eve Single Pro-line, User Manual Alfen Eve Single Pro-line.

Summary

• Very small modern housing
• Charging capacity up to 22kW
• Fixed cable type 1 or 2 (type 2 plug holder integrated)
• Wall-mounted or free-standing with optional mounting pole
• Dynamic load balancing possible in cooperation with smart meter
• Full color 3.5″ display
• Includes RFID card reader
• Display configurable in different languages
• MID certified energy meter for transaction cost settlement
• Sign-in with charging card
• Plug & Charge
• European A-quality: a solid and high-quality product

Technical Specifications

Number of type B residual current devices	1
Number of charging units	1
Protection rating (IP)	IP54
Width	240 mm
Depth	130 mm
Access control function	Yes
Height	370 mm
Housing material	Plastic
Max power per charging point	22 kW
With safety switch	No
With communication interface	Yes
With energy meter	Yes
With load management	Yes
Mounting method	Free-standing mobile
Nominal connection power	22 kW
Separate connection box	No
Impact resistance	IK10
Installation side connection type	3-phase
